FILTER FLUSHER model FFC3S PERFORMANCE
Based on a filter cleaning 5/7/22. Please note the following:
1) System cleaned is a Hayward unit supplied by Shasta Pools in 2005 with 8 cartridges. Each cartridge is 7” outside diameter, 3” inside diameter and 19-5/8” long.
2) Tasks were performed in no particular rush but attention was paid to being efficient as if servicing someone else’s pool for profit.
3) Times listed are in minutes and seconds i.e. 6:01 is 6 minutes and 1 second.
4) The first number is the time required for the task described. The second number (in parentheses) is the total elapsed time at the end of the task described.
5) Peak in-floor cleaning system pressure before servicing was about 21 psi and about 18 psi after.
6) Taking the Filter Flusher from my garage to my patio through my house involves negotiating two self-closing doors. I estimate that is roughly equivalent to taking the unit from a vehicle parked at the curb to the work site and back.
7) Time to exchange cartridges includes several seconds to access my phone and operate the stopwatch function after starting the cleaning cycle.
8) Typical time to clean each cartridge was about 7-1/4 minutes and of that time typically about 6-3/4 minutes was spent sitting watching the machine work. Said another way that’s more than 50 minutes available during this cleaning session to perform additional value added services.
THE CLEANING DATA
6:01 (6:01) Carried machine from garage (or vehicle) to worksite on patio, set machine up, retrieved and connected supply hose, opened filter housing, carried first two cartridges to machine, placed cartridge #1 on machine, and started cleaning cycle
7:17 (13:18) Cleaned cartridge #1 and brought 2 more cartridges to machine.
0:22 (13:40) Removed cartridge #1, placed cartridge #2 on machine, and started cleaning cycle
7:16 (20:56) Cleaned cartridge # 2
0:22 (21:18) Removed cartridge #2, placed cartridge #3 on machine, and started cleaning cycle
7:14 (28:32) Cleaned cartridge #3 brought 4 remaining cartridges to machine
1:44 (30:16) Removed hose from machine, took it to rinse out filter housing, and reconnected the hose to the machine.
0:21 (30:37) Removed cartridge #3, placed cartridge #4 on machine, and started cleaning cycle
7:14 (37:51) Cleaned cartridge #4
0:21 (38:12) Removed cartridge #4, placed cartridge #5 on machine, and started cleaning cycle
7:14 (45:26) Cleaned cartridge #5 and placed 1 through 4 in filter housing while #5 was being cleaned
0:20 (45:46) Removed cartridge #5, placed cartridge #6 on machine, and started cleaning cycle
7:10 (52:56) Cleaned cartridge #6
0:20 (53:17) Removed cartridge #6, placed cartridge #7 on machine, and started cleaning cycle
7:09 (60:26) Cleaned cartridge #7
0:25 (60:51) Removed cartridge #7, placed cartridge #8 on machine, and started cleaning cycle
7:38 (68:29) Cleaned cartridge #8 and placed 5 through 7 in filter housing while #8 was being cleaned
7:51 (76:20) Removed cartridge #8 from machine and placed it in filter housing, closed filter housing, started pump, rinsed off Filter Flusher, configured Filter Flusher for transport (stowed legs), checked filter housing for leaks, took Filter Flusher back to garage (or vehicle).
SUMMARY
The total elapsed time to perform this cleaning service was 76 minutes and 20 seconds or 1 hour 16 minutes and 20 seconds. That represents the time from parking in front of the customer’s location until leaving for the next job. And during that time there was about 50 minutes available to perform additional value added services.
